Generatori di vapore

S-Team 10 TP VH

STEAM GENERATOR S-TEAM 10 TP VH

Cod: 14121610001

Overview

S-Team 10 TP VH is the professional three-phase steam generator designed for deep cleaning and sanitising in industrial environments. Steam production at 185 °C and a high operating pressure of 10 bar, developed by the continuously recharging boiler with a total output of 9000 W, guarantee excellent cleaning and productivity results. The handy control panel allows you to manage all machine operations and to activate the Detergent Function and the Hydrojet Function, which uses a powerful jet of steam mixed with water to tackle stubborn dirt. The S-Team 10 TP VH is extremely sturdy and durable, thanks to its stainless steel frame, and is the ideal steam generator for demanding industrial applications in environments such as wineries, food, chemical and cosmetic industries.

Photo gallery

Technical data

TECHNICAL DATA

  • Max Power9000W
  • Max power consumption9100W
  • Boiler max power9000W
  • Rated boiler capacity4,2l
  • Resistance power9000W
  • Ampère39,6A
  • Pressure10bar
  • Temperature185°C
  • Steam production15kg H2O/h
  • Cleaning solution tank5l
  • Water tank capacity10l
  • IP codeIPX4
  • Power supply cable9,4m
  • Weight (without accessories)41,5Kg
  • Dimensions850x500x1170mm
  • Useful boiler capacity3,82l
  • Voltage - Frequency400 V³ ~ 50 Hz

Standard accessories

  • 6010523FLEXIBLE HOSE STEAM WITH HYDROJET HANDLE (6 M)
  • 2511843STEAM LANCE 450 MM
  • 2511641POLYESTER ROUND BRUSH Ø28
  • 2511844STAINLESS STEEL ROUND BRUSH Ø 28
  • 2511642BRASS ROUND BRUSH Ø28
  • 2511646POLYESTER ROUND BRUSH Ø40
  • 2511647STAINLESS STEEL ROUND BRUSH Ø40
  • 2511648BRASS ROUND BRUSH Ø40
  • 2511643POLYESTER ROUND BRUSH Ø65
  • 2511644STAINLESS STEEL ROUND BRUSH Ø65
  • 2511645BRASS ROUND BRUSH Ø65
  • 2511842TANK SUCTION ACCESSORY

Optional accessories

  • 7509002SUCTION KIT
  • 2511845CONVEYOR BELT CLEANER
  • 2511846FULL FIXED BARREL WASHER
  • 2511814STEAM LANCE 250 MM
  • 2519009VARIABLE WASHING NOZZLE FOR HYDRO HOSE
